Description
3 Axles 60 Tons Bituman Tanker Trailer Function and Introduction:
3 Axles 60 Tons Bituman Tanker Trailer
Bituman Tanker Trailer is an Bituman tanker with a tractor head connected to a trailer. Compared with ordinary single-body Bituman tankers, semi-trailer Bituman tankers can effectively improve transportation efficiency. Under the same tonnage, it can reduce transportation costs and save Bituman consumption.
Bituman Tanker Trailer is divided into two parts, the Bituman tank part and the frame supporting the tank body or the driving part.
The rear part of the semi-trailer Bituman tanker is generally the same, with rear double axles (two axles) and rear triple axles (three axles). The traction head is selected according to the needs. Semi-trailer Bituman tankers are usually called by the brand of the traction head
Tank body of semi-trailer Bituman tanker
1. The tank body is made of 4mm or 6mm high-quality carbon steel produced by the steel company according to national standards. The shape is divided into elliptical or square round tanks, which can hold 1-4 kinds of Bituman products. Heating and insulation series tank bodies can also be produced.
2. Alcohol and chemical tankers are made of stainless steel imported from South Korea with a thickness of 4mm-5mm.
3. All kinds of hydrochloric acid, sulfuric acid, and alkali liquid tankers are made of plastic with a thickness of 12mm-22mm.
4. There are multiple wave-proof partitions in the tank body. High-pressure gas leak detection is used to make the tank body have high strength, stable center of gravity, and safe and stable vehicle transportation.
5. Centrifugal pumps, gear pumps, and stainless steel pumps can be selected according to the purpose of the tanker truck, which have the characteristics of large flow and fast suction speed.
6. For the measurement of Bituman tanker trucks, single-count and double-count flow meters can be selected, and tax-controlled computer reBitumaning machines can also be installed, 10-15 meters of automatic retractable return reels can be installed, and reBitumaning guns can be equipped. Edible Bituman products can be measured by edible Bituman computer meters.
3 Axles 60 Tons Bituman Tanker Trailer Specifications
|
Trailer Model |
3 Axles 60t Bitumen Tank Trailer |
|
Overall Dimension（mm） |
11000x2500x3600mm |
|
Function |
Transport bitumen |
|
Thickness(mm) |
5mm carbon steel +0.6mm galvanized plate |
|
Volume |
30t |
|
Heater |
Diesel heater 220V, itally riello brand |
|
Insulation layer |
50mm thickness, glass wool |
|
Axle |
13Ton FUWA Brand |
|
Axle Number |
Three |
|
Compartment |
3 |
|
Manhole cover |
3pcs, 500mm manhole |
|
Discharge valve |
3 |
|
Suspension system |
Mechanical Suspension |
|
Steel Spring |
10/10/10 leaf spring with 90mm(W) *13mm(thickness) |
|
Tire Type and quantity |
12R22.5 12units |
|
Traction Pin |
90mm |
|
Landing Gear |
Standard brand 28ton external , yahua brand |
|
Spare wheel carrier |
2pcs |
|
Tool box |
1pcs, One crank and one shaft head wrench |
|
Electrical System |
Chinese standard 24V lighting system |
|
Brake |
Dual Lines Pneumatic Brake System. T30/30 Air Chamber; Parking Brake,T30/30 type on each axle |
|
Brake air chamber |
Six big double chamber |
|
Electrical system |
1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) |
|
Tail lamp with turn signal, brake light & reflector, side lamp etc. |
|
|
One set 6-core standard Cable. |
|
|
Packing |
Nude, Polish with wax before shipping |
3 Axles 60 Tons Bituman Tanker Trailer Pictures and Delivery
FAQ for 3 Axles 60 Tons Bituman Tanker Trailer
Q: Are you Dealer or Factory for 3 Axles 60 Tons Bituman Tanker Trailer?
A: We are the factory, and we produce more than 20 years already.
Q: What is shipping method of the 3 Axles 60 Tons Bituman Tanker Trailer?
A: We can ship the trucks as per the destination shipping lines, choose the fastest and most Economic shipping method to ensure customer received the cargo on time and safely.
Q: I want to transport the 3 Axles 60 Tons Bituman Tanker Trailer by container, is it ok?
A: Yes, it is ok. but we need to detached the truck and you should assemble in your country., and you can also choose by flatrack contianer or roro or bulk shipping to ensure the trucks complete.
Q: How about your 3 Axles 60 Tons Bituman Tanker Trailer quality?
A: All the trucks are Original, the quality is 100% guaranteed and we have one years warranty for Sinotruk and two years for Shacman.
Q: I want to be your agent in my country for 3 Axles 60 Tons Bituman Tanker Trailer. is that ok?
A: lt's ok to be agent but need minimum one year order 200 units to be the sole agent, but if not sole agent then 5 units is ok to be normal agent.
Q: How about your company's service for 3 Axles 60 Tons Bituman Tanker Trailer, especially after-sale service?
A: SINOTRUK/SHACMAN has many after sales service station over the world, we can also provide spare parts from China for you to guarantee the Vehicles works well.
Q: What is your payment terms for 3 Axles 60 Tons Bituman Tanker Trailer?
A: TT Payment, Normally its 30% prepaid and 70% balance before delivery
Q：what is the production time for 3 Axles 60 Tons Bituman Tanker Trailer?
A: Production time: Normally within 30 workdays after received deposit, some trucks and trailers we have stock so we can deliver quickly.
Q：What is your company after sales Service for 3 Axles 60 Tons Bituman Tanker Trailer?
A: our warranty and guarantee is one year or 30,0000km which comes first which is the Warranty.
Our Advantages for 3 Axles 60 Tons Bituman Tanker Trailer:
20 Years Of Production Experience
Advanced Production Line
Strong Scientific Research Strength
Reliable Quality
Professional And Timely Service
Compulsory maintenance for 3 Axles 60 Tons Bituman Tanker Trailer:
In order to eliminate particles, burrs and other harmful magazines worn down by the initial operation of the 3 Axles 60 Tons Bituman Tanker Trailerand the loosening of various connectors caused by the initial operation, eliminate the hidden trouble, improve the reliability of the vehicle, make the 3 Axles 60 Tons Bituman Tanker Trailerin the best working condition, extend the service life of the vehicle, and maintain the economic interests of customers, during the new car running, within the limited mileage, Measures to require customers to come to service station for maintenance according to the specified items.
3 Axles 60 Tons Bituman Tanker Trailermileage between 3000-5000 km or within 3 months from the date of purchase, must go to the service station for compulsory maintenance of the vehicle.
Regular maintenance for 3 Axles 60 Tons Bituman Tanker Trailer:
After the compulsory maintenance of the new car, the vehicle will be maintained at service station every certain mileage according to the regular maintenance project. The main content of regular maintenance is to check, maintain and eliminate hidden trouble so as to reduce the failure of the vehicle.
Customer Feedback for 3 Axles 60 Tons Bituman Tanker Trailer:
“ Howo Truck Export can provide timely service, the 3 Axles 60 Tons Bituman Tanker Trailertrucks already put into use more than one year, all goes well, I also buy spare parts its good quality, they are trustable. ”
--Mr.Siadou kokou
“ I order 3 Axles 60 Tons Bituman Tanker Trailerand the shipping and production is faster than other supplier, i will introduce this company to my friends ”
--Mr.Nana Wilberforce
