Description
Standard Specification
|
General |
1 |
Model |
|
CPQYD25FR |
|
2 |
Rated capacity |
kg |
2500 |
|
|
3 |
Load center |
mm |
500 |
|
|
4 |
Power type |
|
||
|
5 |
Transmission |
|
Hydraulic |
|
|
Dimensions |
6 |
Lifting height |
mm |
3000 |
|
7 |
Free lifting height |
mm |
60 |
|
|
8 |
Turning radius |
mm |
2450 |
|
|
9 |
Overall length |
mm |
3605 |
|
|
10 |
Overall width |
mm |
1160 |
|
|
11 |
Overall height (mast lowered) |
mm |
2095 |
|
|
12 |
Overall height (mast raised) |
mm |
4080 |
|
|
13 |
Overall height (overhead guard) |
mm |
2095 |
|
|
14 |
Fork length |
mm |
1070 |
|
|
15 |
Fork width |
mm |
122 |
|
|
16 |
Fork thickness |
mm |
40 |
|
|
Performance |
17 |
Max. driving speed (with/without load) |
km/h |
17/19 |
|
18 |
Max. lifting speed (with load) |
mm/s |
400 |
|
|
19 |
Max. traction (with/without load) |
kn |
15/10 |
|
|
20 |
Gradeability (with/without load) |
% |
15/20 |
|
|
21 |
Tilting angles (forward/backward) |
° |
6/12 |
|
|
22 |
Service weight |
kg |
3600 |
|
|
Engine |
23 |
Engine model |
|
BY491GP engine |
|
24 |
Power |
kw |
41 |
|
|
25 |
Rated speed |
rpm |
2800 |
|
|
26 |
Displacement |
L |
2.237 |
|
|
27 |
No. of cylinder |
|
4 |
|
|
Wheel |
28 |
Front overhang |
mm |
451 |
|
29 |
Wheel base |
mm |
1640 |
|
|
30 |
Front tread |
mm |
970 |
|
|
31 |
Rear tread |
mm |
970 |
|
|
32 |
Front tire |
|
7.00-12 |
|
|
33 |
Rear tire |
|
6.00-9 |
Optional Equipment:
Optional Engine:Mitsubishi 4G64
Nissan K25 44Kw
Tire:Solid tire
Dual pneumatic front wheel
Side Shifter
Electric Shift
Cab:Fan,Heat
Seat:Good Seat(Toyota)/TOYOTA DAMPING SEAT
Mast:Full-free Lift mast
2-Stage Mast 3.3/3.5/4/5M
3-Stage Mast 7.3/6/5.5/5/4.8/4.5M
Special forks:Length 1220/1370/1520/1820/2000/2200/2500mm
Fork special for Handling stone/fertilizer
Attachment:BUCKET,HINGED FORK,Fork positioner
Fork cover 1.8/2/2.4M
