Description
Standard Specification
|
General |
1 |
Model |
|
CPD20C |
|
2 |
Rated capacity |
kg |
2000 |
|
|
3 |
Load center |
mm |
500 |
|
|
4 |
Power type |
|
Battery |
|
|
Dimensions |
5 |
Lifting height |
mm |
3000 |
|
6 |
Free lifting height |
mm |
60 |
|
|
7 |
Turning radius |
mm |
2200 |
|
|
8 |
Overall length |
mm |
3350 |
|
|
9 |
Overall width |
mm |
1160 |
|
|
10 |
Overall height (mast lowered) |
mm |
2130 |
|
|
11 |
Overall height (mast raised) |
mm |
4040 |
|
|
12 |
Overall height (overhead guard) |
mm |
2130 |
|
|
13 |
Fork length |
mm |
1070 |
|
|
14 |
Fork width |
mm |
100 |
|
|
15 |
Fork thickness |
mm |
40 |
|
|
Performance |
16 |
Max. driving speed (with/without load) |
km/h |
12.5/14 |
|
17 |
Max. lifting speed (with load) |
mm/s |
250 |
|
|
18 |
Max. traction (with load) |
kn |
10 |
|
|
19 |
Gradeability (with load) |
% |
15 |
|
|
20 |
Tilting angles (forward/backward) |
° |
6/12 |
|
|
21 |
Service weight |
kg |
3950 |
|
|
Motor |
22 |
Traction motor |
|
XQ-8 |
|
23 |
Lifting motor |
|
XQD-10-3S |
|
|
Battery |
24 |
Battery type |
|
D-600 |
|
25 |
Battery voltage/capacity |
V/Ah |
48/600 |
|
|
Wheel |
26 |
Front overhang |
mm |
451 |
|
27 |
Wheel base |
mm |
1550 |
|
|
28 |
Front tread |
mm |
970 |
|
|
29 |
Rear tread |
mm |
950 |
|
|
30 |
Front tire |
|
7.00-12 |
|
|
31 |
Rear tire |
|
18×7-8 |
Optional equipment:
Front-moving fork
Solid tyres
Side Shifter
Cab:Fan,Heat
Seat:Good Seat(Toyota)/TOYOTA DAMPING SEAT
Mast:Full-free Lift mast
2-Stage Mast 3.3/3.5/4/5M
3-Stage Mast 7.3/6/5.5/5/4.8/4.5M
Special forks:Length 1220/1370/1520/1820/2000/2200/2500mm
Fork special for Handling stone
Fork cover 1.8/2/2.4M
